Parcel lockers - technical information

Technical information

Terminal stations with high capacity and a wide range of functionalities

AlfaBOX delivery machines with an integrated terminal unit are connected to a permanent power supply. They use the possibility of connection via LAN or mobile data networks for data communication. The device contains a special microcomputer that provides flexible and wide-ranging functionality, including a payment terminal, scanner, security cameras, indoor and outdoor lighting system, and monitoring of electricity consumption and other functions. AlfaBOX terminal machines are designed to serve as a fundamental building block in large-scale distribution networks with high volumes of shipments. They are optimized for both receiving and dispatching processes.

Off-grid  stations

Off-grid parcel delivery stations are growing in popularity due to their energy independence, environmental friendliness and innovative approach to last – and first-mile logistics. They use solar energy to power batteries and are equipped with energy-saving electronics with mobile data transmission, display, keyboard and scanner. This enables efficient communication with the operator's logistics systems and offers a user-friendly environment for the client and courier. We have designed the stations for flexible use in urban and rural areas. Their easy relocatability also allows us to test the demand for delivery services in a specific location.

Safety and long-term durability

The AlfaBOX parcel boxes are designed to meet the highest safety and structural stability requirements. The unique double-plated door construction is an important feature that increases their resistance. This innovative solution complements the robust frame design of the bodies and other security features that improve the security effectiveness of the entire system.

Corrosion and weather resistance

It is a key area we have paid close attention to. The construction of galvanized rolled steel with a high-quality facade powder coating ensures that AlfaBOXes are corrosion resistant under ISO 12944 in environmental aggressiveness category C3, with high durability. In addition, specific technical solutions effectively prevent rainwater ingress and protect the interior of the boxes and other components from moisture.

Easy scalability

AlfaBOX is an innovative design system that has been carefully engineered to allow the customization of the boxes. We offer a wide range of already configured units. We are ready to produce units with individually tailored dimensions for larger-scale projects.It is possible to expand the capacity of the equipment by gradually adding more cabinet units up to a range of 144 boxes.

Anchoring systems

We prefer the anchoring method for terminal and high-capacity models, which uses the fixed anchoring eye of the height-adjustable legs to the base plate. This approach incorporates integrated telescopic cover panels to cover the space under the box effectively.

We recommend a sturdy base with concrete ballast for off-grid models for height leveling. Additionally, when placed in an open area, we recommend the option of additional anchoring to increase stability and safety in the event of extremely high winds.

Reliable electronic equipment

Our electronic locks and control electronics are designed for the specific needs of parcel delivery boxes. We produce a mains-powered version of the electronics that integrates a wide range of peripherals and energy-saving electronics for battery-powered boxes recharged by solar panels. We also have extensive experience in implementing control electronics provided directly by the client.

Advanced software

The software for the AlfaBOX system is designed to comprehensively and efficiently handle all logistics operations for both the customer and the courier. It includes a wide range of functions - from operational to service to security. We provide secure transfer of encrypted data from our devices to cloud storage using LAN or mobile technologies. It can also be integrated with customers' business systems to allow seamless two-way communication.

In addition, clients have a user-friendly web interface for system administration. To interact via Bluetooth and a mobile app on the customer's or courier's smart device is also available.

Our platform is equipped with advanced predictive maintenance tools. It enables efficient handling of standard service interventions by continuously monitoring the operating parameters of key equipment components and the ability to perform specific maintenance tasks remotely. All of this contributes to the maximum efficiency and reliability of our AlfaBOX devices.

Smart and economical lighting

Our equipment can automatically activate an internal lighting system when the locker door is opened. To provide external lighting, we offer the possibility of integrating lighting elements into roof panels or plinths and installing backlighting for graphic advertising elements located on the outer shell of the device.

The exterior lighting is controlled by a system that always calculates the right time to switch on and off based on geolocation data. We can also work with lower lighting intensity and gently increase it when the customer approaches the device. This smart feature is essential for reducing light smog and saving electricity.

Security camera systems

We recommend equipping on-grid package boxes with a security camera system in regions where legislation allows it. This system should include a face camera and an overview camera to monitor the area in front of all boxes.

This will provide the operators of the parcel box network with an important tool to verify the proper handling of parcels. In addition, it will allow them to use the footage to identify offenders in cases of vandalism or attempted break-ins.

Technical parameters

• Corrosion protection parameters for exterior versions according to ISO 12944
• Corrosion aggressiveness C3
• Durability level high (15-25 years)
• Verified by neutral salt spray test according to ISO 9227 (480 hours)
